The new L1 Compact system combines conventional PA and monitors into one sleek unit. It’s our smallest, lightest, easiest-to-set-up L1 system, weighing just 29 pounds.
Our smallest and most portable system for an audience of up to 100. It has a six-speaker articulated line array, and it includes an integrated two-channel mixer with ToneMatch® presets on each channel. Carry it in one trip. Set it up in one minute. Fill the room with one system.
For indoor applications only.
Features
High-performing, powered, portable two-way loudspeaker system with a 180° H x 40° V nominal dispersion designed for the production and reproduction of live music, music playback, speeches and A/V sound reproduction
Articulated line array loudspeaker technology produces wide, uniform sound coverage throughout the entire listening area—even off to the extreme sides
Curved array design provides 40° of vertical coverage
Integrated ToneMatch® presets contain hardwired equalization curves for dynamic handheld microphones and acoustic guitars
Lightweight, interlocking components for easy transport
Offers both collapsed and extended setup positions
Applications
- Houses of worship
- Schools and universities
- Resorts and hospitality venues
- Live music performances
- Business presentations
- Mobile DJs
Specs
Technical Summary
Frequency Response (+/-3 dB)
65 Hz – 14 kHz
Frequency Range (-10 dB)
50 Hz – 16 kHz
Nominal Dispersion
180° H x 40° V
Maximum SPL @ 1 m
106 dB SPL (112 dB SPL peak)
