High power compact 5.1 channel surround system with DAB+ digital radio, Dolby Atmos® and DTS:X® 3.1.2 playback. Supports 4K/60p Ultra HD, HDR 10 and Dolby Vision. Available for demonstration
Onkyo 5.1 Surround Package with DAB+ radio and Atmos 3.1.2 – HT-S3910DAB-B
€699
In stock
In stock
Description
Start the next season with life-changing sound
Experience the ultimate in pure sound flexibility. The powerful yet compact HT-S3910DAB transforms tiny TV sound into a thrilling sonic sensation with Dolby Atmos® and DTS:X® playback through 3.1.2 channels. Legacy soundtracks are remapped to localize sound and add height dimensionality or enjoy 3D immersion without height or rear speakers connected thanks to Dolby Atmos Height Virtualizer* and DTS Virtual:X™ technologies, which place you at the heart of the event. Support for 4K/60p and HDR primes you for next-gen Ultra HD content. Power an HDMI® network dongle via USB terminal or enjoy streaming audio with Bluetooth® technology. Advanced Music Optimizer™ works magic on lossy audio. Everything you need is in the box, right down to cables to connect factory-matched speakers. These full-range units love high-current power, so turn it up and enjoy home entertainment as it’s meant to be.
Product highlights
- 155 watts per channel
- Supports 4K/60p and HDR (HDR10, HLG, Dolby Vision®, BT.2020)
- Dolby Atmos® and DTS:X® playback
- Dolby Atmos Height Virtualizer* and DTS Virtual:X™
- Discrete high-current analog amp system with 4-ohm drive capability
- Bluetooth® technology and Advanced Music Optimizer™
- Vocal Enhancer function improves voice audibility
- Zone B analog RCA line-output connects compatible devices such as wireless headphone transmitters or hi-fi systems to enable audio playback in Zone B or Main + Zone B simultaneously (including HDMI®/SPDIF)
- OSD window shows media format data for quick confirmation
- FM/DAB+ Reception
Specifications
Product Attributes
EAN
4573211159035
Product Weight
14.9 kilograms
Manufacturer number
HT-S3910DAB(B)MMP
Amplifier Section
Rated Output Power (IEC)
5 ch × 135 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
1 ch × 100 W at 6 ohms, 100 Hz, 1 ch driven of 1% THD (SUBWOOFER)
Maximum Effective Output Power (IEC)
5 ch × 155 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
1 ch × 125 W at 6 ohms, 100 Hz, 1 ch driven of 10% THD (SUBWOOFER)
Dynamic Power (*)
* IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz – 20,000 Hz, half power)
Input Sensitivity and Impedance
200 mV/47 kΩ (LINE (RCA))
Rated RCA Output Level and Impedance
1 V/470 Ω (SUBWOOFER PRE OUT)
1 V/2.3 kΩ (ZONE B LINE OUT)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
109 dB (IHF-A, LINE IN, SP OUT)
Speaker Impedance
4 Ω – 16 Ω
Headphone Rated Output
80 mW + 80 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones
8 Ω – 600 Ω
Headphones Frequency Response
10 Hz – 100 kHz
Tuner Section
FM Tuning Frequency Range
87.5 MHz – 108.0 MHz, RDS
50 dB quieting sensitivity (FM MONO)
1.0 μV, 11.2 dBf (IHF, 1 kHz, 100% MOD)
DAB Tuning Frequency Range
174.928 MHz – 239.200 MHz (Band III)
DAB Sensitivity
-100 dBm (Min.) (Band III)
Preset Channel
40
Bluetooth Section
Communication system
BLUETOOTH Specification version 4.2
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.3
AVRCP 1.5
HFP(Hands-Free Profile) 1.6
HSP(Headset Profile) 1.2
SPP(Serial Port Profile) 1.2
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz – 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (*)
* The actual range will vary depending on factors such as obstacles between devices, magnetic fields around a microwave oven, static electricity, cordless phone, reception sensitivity, antenna’s performance, operating the system, software application, etc.
General
Power Supply
AC 220 – 240 V, 50/60 Hz
Power Consumption
465 W
0.2 W (Full Standby mode)
0.2 W (HDMI CEC)
36.1 W (No-sound)
24.4 W (HDMI Standby Through)
Dimensions (W × H × D)
435 mm × 160 mm × 328 mm
17-1/8″ × 6-5/16″ × 12-15/16″
Weight
8.2 kg (18.1 lbs.)
Maximum radio-frequency power transmitted in the frequency band(s)
2402 MHz – 2480 MHz (4 dBm (e.i.r.p))
HDMI
Input
IN1 (BD/DVD), IN2 (GAME), IN3 (CBL/SAT), IN4 (STRM BOX)
Output
OUT
Supported
Audio Return Channel, 3D, 4K 60 Hz, 6G, HDR10, BT.2020, HLG, Dolby
Vision, Auto Lip-Sync, CEC
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS, DTS:X,
DTS-HD Master Audio, DTS-HD High-Resolution Audio, DTS 96/24, DTS-ES, DTS Express, DSD (PCM Conversion Input), 2-channel Linear PCM,
Multi-channel Linear PCM
HDCP version
2.2
Maximum Video Resolution
4K 60 Hz (YCbCr 4:4:4)
Supported Input Resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
• Signals are output from the HDMI OUT jack of this unit to the TV with the
same resolution as the input resolution. When using a TV that supports 4K,
1080p HDMI video signals can also be output as 4K.
Audio Inputs
Digital
OPTICAL (TV)
COAXIAL (CD)
Analog
CD, TV, PC, AUX (front)
Audio Outputs
Analog
ZONE B LINE OUT
2 SUBWOOFER PRE-OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R, SUBWOOFER
Phones
PHONES (Front, ø 6.3 mm, 1/4″)
Front speaker (SKF-398)
Speaker Type
Full-Range, Acoustic-Suspension
Drivers
3″ (7.7 cm) Cone
Frequency Response
80 Hz – 20 kHz
Output Sound Pressure Level
80 dB/W/m
Maximum Input Power
150 W
Normal Impedance
6 Ω
Dimensions (W × H × D)
98.5 mm × 140.5 mm × 106 mm
3-7/8″ × 5-1/2″ × 4-3/16″
Weight
0.5 kg (1.1 lbs)
Center speaker (SKC-398)
Speaker Type
Full-Range, Acoustic-Suspension
Drivers
3″ (7.7 cm) Cone
Frequency Response
70 Hz – 20 kHz
Output Sound Pressure Level
80 dB/W/m
Maximum Input Power
150 W
Normal Impedance
6 Ω
Dimensions (W × H × D)
244 mm × 96 mm × 102 mm
9-5/8″ × 3-13/16″ × 4″
Weight
0.6 kg (1.3 lbs)
Surround speaker (SKR-398)
Speaker Type
Full-Range, Acoustic-Suspension
Drivers
3″ (7.7 cm) Cone
Frequency Response
80 Hz – 20 kHz
Output Sound Pressure Level
80 dB/W/m
Maximum Input Power
150 W
Normal Impedance
6 Ω
Dimensions (W × H × D)
98.5 mm × 140.5 mm × 106 mm
3-7/8″ × 5-1/2″ × 4-3/16″
Weight
0.5 kg (1.1 lbs)
Subwoofer (SKW-398)
Speaker Type
Bass Reflex
Drivers
6-7/16″ (16 cm) Cone
Frequency Response
28 Hz – 5 kHz
Output Sound Pressure Level
78 dB/W/m
Maximum Input Power
120 W
Normal Impedance
6 Ω
Dimensions (W × H × D)
230 mm × 389 mm × 331.5 mm
9-1/16″ × 15-5/16″ × 13-1/4″
Weight
4.6 kg (10.1 lbs)
Others
USB: 1 (Only for supplying power to Streaming media player, 5 V/1.0 A)
Specifications and features are subject to change without notice.
