Frequency Response 50 Hz — 30 kHz
Sensitivity (1W@1M) 89 dB
Nominal Impedance 8 ohms
Maximum SPL 109 dBA
Power Handling (RMS) 100 W
Recommended Amplifier Requirements 20 — 100 W
Drivers 8″ C-CAM cone bass driver 1″ C-CAM Gold Dome tweeter (fixed angle)
Controls HF Level Switch (+3 dB / 0 dB / -3 dB) – Adjustable at the point of installation
Adjustment Controls 2 x (1 pair) Gold plated push style terminal
Overall Diameter (Including Grille) 285 mm (111/4″)
Overall Depth (Including Grille) 102.5 mm (41/32″)
Cut-Out Hole Diameter 247 mm (93/4″)
Mounting Depth 97.6 mm (37/8″)
Optional Square Grille – Outer Dimensions 285 x 285 mm (111/4″)
Fixing Type 3 position Tri-Grip dog leg fixings
Construction Material Mineral Filled PC-ABS Polymer (UL V0 Fire Retardant, RoHS2 Compliant)
Grille SS430 Stainless Steel
Magnets Samarium Cobalt
Operating Temperature Range -34° to 79° C -29° to 174° F
Weight 2.8 kg (6 lb 2 oz)
Pre-Construction Bracket CB8 Pre-Construction Bracket (Green)
Back Box CCBOX-R | CMBOX-R
Sold As Single Unit
