Fonestar Speaker ceiling – Sky-8

69

In stock

The SKY-8 is a low impedance ceiling loudspeaker designed for high quality sound and functional design. Its frameless, low-profile grille, made of rust-resistant aluminium, provides a modern, unobtrusive aesthetic, ideal for any space. In addition, it can be customised thanks to its removable, paintable design without visible logo.

In stock

Description

Speakers Ceiling SKY-8

8” low impedance ceiling loudspeaker

Robust and versatile design for quality installations

The SKY-8 is a low impedance ceiling loudspeaker designed for high quality sound and functional design. Its frameless, low-profile grille, made of rust-resistant aluminium, provides a modern, unobtrusive aesthetic, ideal for any space. In addition, it can be customised thanks to its removable, paintable design without visible logo.

Maximum acoustic performance with easy installation

The SKY-8 combines power and precision in its performance:

  • Power: up to 27 W maximum with a wide frequency response of 40-15,000 Hz.
  • 8’ polypropylene cone: double diaphragm for greater fidelity.
  • Advanced protection: IP-44 rated against dust and water, suitable for demanding conditions.

In addition, installation is simple and safe:

  • Highly conductive quick-connect terminals.
  • Anti-fall system and hooks for safety cables.
  • Stable mounting brackets ensure reliable mounting.

Why choose SKY-8?

Designed for professional installers, the SKY-8 is ideal for projects that demand:

  • Reliability: durable materials such as ABS with UV resistance and aluminium with anti-corrosion paint.
  • Adaptability: paintable design to suit any environment.
  • Precise acoustic coverage: defined angles for optimal sound dispersion indoors.

The SKY-8 guarantees a perfect balance between aesthetics, functionality and durability, making it an outstanding solution for commercial and industrial applications.

Technical Specs

Features:– Low impedance ceiling loudspeaker.
– Low profile frameless grille, constructed from rust resistant aluminium. Detachable, turn-lockable grille. The logo can be removed and painted.
– Fast connection terminals and high conductivity.
– Anti-fall system for installation assistance.
– Hook for safety cable.
– Stable, worm-gear ceiling brackets.
– Protection against dust and water.
Power:– 20 W RMS
– 27 W MAX.
Speakers:8” polypropylene double cone diaphragm
Response:– 40-15,000 Hz @ -10 dB
– 90-15,500 Hz @ -3 dB
Impedance:8 Ω
Sensitivity:88 dB @ 1 W/1 m
Maximum sound
pressure:
– 103 dB @ max. W/1m Continuous
– 105 dB @ max. W/1m Peak
Coverage angle:H/V (-6 dB): 70º@500Hz, 90º@1kHz, 70º@2kHz, 50º@4kHz
Protections:
– IP-44 in compliance with IEC 60529
– EN ISO 9227:2006 Neutral Salt Spray Test
Material:– ABS (UV resistant)
– Liquid painted aluminium grille
Connectors:– Highly conductive quick-connect terminals
– For cable cross-section 0.4 ~ 4 mm².
Operation Temperature:-20ºC ~ 70°C (48 h)
Storage Temperature:10ºC ~ 40°C
Maximum Humidity:95%
Colour:White (RAL 9003)
Dimensions:Total loudspeaker: 306 mm Ø x 114 mm height
Grille section: 7 mm
Recessed height: 107 mm
Installation hole: 273 mm Ø
Maximum ceiling thickness: 30 mm
Weight:1.3 kg
Accesories:Installation template
