Bose LT6400 medium-format waveguide and 60° x 40° pattern designed as the primary reinforcement source for medium to large venues.
Medium-format waveguide and 60° x 40° pattern designed for downfill applications with LT Coherent Zone arrays in medium to large permanent installations, or as the primary reinforcement source along with MB low-frequency loudspeakers in smaller arrays and venues.
For indoor applications only.
Features
60° x 40° coverage for medium-throw applications in auditoriums, worship facilities, performing arts centers, stadiums and arenas
Mid/high-frequency loudspeaker designed for use in arrays with separate LF augmentation (Bose® MB12 or MB24 bass arrays) or voice-only applications
Bose V2 midrange manifold sums output of 2 x 4.5″ (114 mm) extended-range cone drivers for lower breakup distortion and improved transient response. Provides a smoother, more natural vocal range compared to single 8″ to 12″ woofers. The LT 6400 loudspeaker utilizes a single Bose V2 midrange manifold
Bose large-format waveguide provides effective 60° x 40° pattern control to approximately 1 kHz (horizontal) and 1.5 kHz (vertical). Minimizes loudspeaker overlap in arrays to reduce comb-filter interference and improve intelligibility
Applications
- Indoor arenas
- Houses of worship
- Auditoriums
- Performing arts venues
Specs
Technical Summary
Frequency Response (+/-3 dB)
190 Hz – 16 kHz
Frequency Range (-10 dB)
170 Hz – 18 kHz
Nominal Dispersion
60° H x 40° V
Sensitivity (SPL / 1 W @ 1 m)
105 dB SPL
Maximum SPL @ 1 m
125 dB SPL (131 dB SPL peak)
Long-Term Power Handling
100 W (400 W peak)
Nominal Impedance
8 Ω
