Audac CIRA5

49.1061.60

5 ¼” driver, 1” Mylar tweeter, phase plug, 30 Watt (RMS) and 60 watt (MAX), 100V line with tappings for 24W, 12W, 6W, 3W, 1.5W and an 8 Ohm or 16 Ohm bypass connection.

Description

Designed to offer the best value for money ratio. The CIRA series are coaxial 2-way ceiling speakers featuring exceptional intelligibility and musical performance. The TwistFix™ borderless grill design offers easy but solid assembly and a completely seamless transition from grill to ceiling. This results in a perfect blend in to its environment. The QuickFit™ installation system combined with FastCon™ connector offers lifetime stability and great installers convenience.

The CIRA5 features a 5 ¼” driver using polypropylene cone material, combined with a 1” Mylar tweeter fitted with a phase plug for excellent off axis performance. The selected materials guarantee a low distortion performance with smooth and flat frequency response. A continuous power handling of 30 Watt (RMS) and maximum power handling of 60 watt is achieved, while fitted with a multi-tapping 100V line transformer with tappings for 24W, 12W, 6W, 3W, 1.5W and an 8 Ohm or 16 Ohm bypass connection.

VARIANTS

  • New CIRA506/W – White version, 8Ω & 6 Watt @ 100V
  • New CIRA524/W – White version, 8Ω & 24 Watt @ 100V
  • New CIRA530D/W – White version, 16 Ω

SYSTEM SPECIFICATIONS

Max. Power 60 W
RMS Power 30 W
Sensitivity (1W/1m) 87 dB
Speaker type 2-way coaxial
Impedance 16 Ω (CIRA530D)
8 Ω (CIRA506 & CIRA524)
Connectors Multi-tap Fast-con™ connections
Sound Pressure (Max. W/1m) @ 100 V 102 dB
Frequency Response (± 3 dB) 60 Hz – 20 kHz
Range (-10 dB) 45 Hz – 20 kHz
Dispersion Conical 145°
Drivers LF 5 ¼” Woofer
HF 1”
Line Transformer Tappings 1 6 W – 1667 Ω (CIRA506)
24 W – 417 Ω (CIRA524)
2 3 W – 3333 Ω (CIRA506)
12 W – 833 Ω (CIRA524)
3 1.5 W – 6667 Ω (CIRA506)
6 W – 1667 Ω (CIRA524)

PRODUCT FEATURES

Cut-out measurement 170 mm (Ø)
Dimensions 193 x 83 mm (Ø x D)
Weight 1.10 kg (CIRA506)
1.15 kg (CIRA524)
1.05 kg (CIRA530D)
Construction ABS
Front finish TwistFix™Borderless finely perforated steel grill
Mounting Quick-Fit™ mounting system
Colours White (RAL9003) (CIRA506/W, CIRA524/W & CIRA530D/W)
Built-in depth 83 mm (CIRA524)
75 mm (CIRA506 & CIRA530D)
Dimensions 193 mm (Ø)

Additional information

Brand

Audac

Speaker Type

Ceiling, 100 Volt

Product Variable

CIRA506W, CIRA524B, CIRA524W, CIRA530DW
