Audac CEP803 – Amplifier

833.50

In stock

The CEP series are professional 70/100V multi-channel energy-efficient amplifiers. The one unit height device comes into two models. The CEP803 offers eight channels and has an output power of 30 Watt.. Both low impedance as 70/100V, deliver high-quality amplification distributed over multiple zones in various applications.

Octo channel 4 Ohm energy-efficient amplifier – 8 x 30W – 70/100V

  • Energy star certified
  • Terminal block input connections
  • Input linking through miniature switches
  • Terminal block output connections
  • Compact and lightweight design
  • Class-D amplifier technology

In stock

Description

CEP SERIES

Energyefficient powerr amplifiers

Professional 70/100V multi-channel highly energy-efficient amplifiers. These amplifiers deliver an uncompromised sound experience in the most effective way.



The CEP series are professional 70/100V multi-channel energy-efficient amplifiers. The one unit height device comes into two models. The CEP803 offers eight channels and has an output power of 30 Watt. Both low impedance as 70/100V, deliver high-quality amplification distributed over multiple zones in various applications. With its compact and lightweight design, the CEP series is designed with high efficiency and reliability by providing input linking through miniature switches at the back of the device in combination with Class-D amplifier technology. These switches allow daisy linking inputs from one channel to another by simply pressing the switch.

The highly efficient Class-D amplifier technology delivers an uncompromised sound experience in the most effective way. The input connections are performed with 3-Pin Terminal block connectors while the output connections are performed with a 4-pin Terminal block connector.

The multi-channel amplifier is Energy Star compliant yet can be enabled or disabled with a standby switch on the back of the device. This amplifier is an HE (1RU) 19” unit. In order to ensure maximum installer/maintenance convenience, the CEP is passively cooled.

less-energy

ENERGY STAR CERTIFIED

Same power, less energy usage

These multi-channel amplifiers are ENERGY STAR® compliant yet can be enabled or disabled with a standby switch on the back of the device, which enables or disables the ‘Auto standby mode’.



silent-passive

A QUIET SOLUTION

Silent passive cooling

In order to reach maximum installer and maintenance convenience all CEP series devices are fully passively cooled. This is an energy-efficient and silent solution for its cooling needs

g
uncompromised-sound-experience

USER-FRIENDLY SETUP

Uncompromised sound experience

The highly efficient Class-D amplifier technology delivers an uncompromised sound experience in the most effective way. Miniature switches at the back allow you to daisy link inputs from one channel to another by just a single press on the switch.

amplifications

MANY DIFFERENT APPLICATIONS

Amplification for any application

These both low impedance as 70/100V amplifiers are designed to deliver high-quality amplification, distributed over multiple zones, like small offices, retail or a school environment.

Technical Specifications

System specifications

RMS/AES power handling

Signal/Noise

THD+N (@ 1 kHz)

Crosstalk (@ 1 kHz)

Frequency

Technology

Protection

@ 4Ω

@ 70V

@ 100V

Response (± 3 dB)

8 x 30W

8 x 30W

8 x 30W

>100dB

< 0.05% (1/8 rated Power)

< 70 dB

110 Hz – 20 kHz

Class-D

DC Short circuit

Over heating

Over load

Signal limiting

Cooling

Operating temperature

Convection cooled

0° ~ 40° @ 95% Humidity

Power

Supply

Source

 Consumption Standby

Idle

Nominal (1/3 MUP)

Nominal (1/8 MUP)

Switching mode

100 ~ 240 V AC / 50 ~ 60 Hz

0.6 W

17.5 W

150 W

68 W

Inputs

Connector

IEC C14 Connector

Input linking through miniature switches

Connector

3-pin Euro Terminal Block (Pitch – 3.81 mm)

Outputs

Inputs

Outputs

Connector

Sensitivity

Voltage / Impedance

4-pin Euro Terminal Block (Pitch – 5.08 mm)

-0.5 dB ~ 10.5 dB

4 Ω

70 V / 167 Ω

100 V / 333 Ω

Product Features

Mounting

Unit height

Colours

Dimensions

Weight

Construction

19″

1HE

Black

482 x 44 x 355 mm (W x H x D)

6 kg

Steel

Recommended Applications

Bars & Restaurants

Corporate

Education

Retail

Downloads

Additional information

Brand

Audac

Amplifier Connectivity

4 Channel
