Audac APT20


In stock

Audac professional Dual Phantom Power Supply

In stock


Audac APT20 Dual Phantom Power Supply – Doneo Malta

The APT20 is phantom power supply unit containing two independent working channels for use with two condenser microphones. It supplies 48V DC to the microphones and routes the signal to a mixer or microphone amplifier. The connections are performed by using XLR connectors for the in- and outputs and at the back, there is an IEC power connector with power switch provided for connecting the APT20 to the mains network.

Phantom Power 48 V DC
THD+N (@ 1 kHz) < 0.0005%
Signal / Noise > 90 dB
Inputs Connector 3-pin XLR female
Outputs Connector 3-pin XLR male
Frequency Response (± 3 dB) 20 Hz – 20 kHz
Power Consumption 3 W
Connector 1 x IEC Mains connector with fuse
Supply 230 V AC / 50 Hz
Product features
Dimensions 110 x 44 x 160 mm (W x H x D)
Weight 0.490 kg
Construction Aluminium
Colours Black

Additional information



Product Type

Power Supplies
