‘Connect’ IP Control Yes
Channel Number 2 (1 Stereo Pair)
Power (W / Channel) | 4 ohms 200 W
Power (W / Channel) | 8 ohms 150 W
Power (W / Channel) | Bridge (8 ohms) 470 W (1CH)
Power (W / Channel) | 70V N/A
Input Impedance 20 K ohms
Output Impedance (Loop RCA) 600 ohms
Input Sensitivity 100 mV / 1 W, 1230 mV – Full power
Maximum Input Voltage 2.9 V
Signal to Noise (SN:R) -100 dB (20 Hz – 20 kHz)
Frequency Response 5 Hz – 50 kHz
Total Harmonic Distortion THD + N@1 KHz 0.03%
Rack Height 1U
Dimensions (Excluding Feet (H x W x D)) 42.4 x 438 x 427 mm (111/16 x 171/4 x 1613/16″)
Dimensions (Including Feet (H x W x D)) 52.8 x 438 x 427 mm (21/16 x 171/4 x 1613/16″)
Width (including rack brackets) 482 mm (19″)
IP Communication TCP/IP (RJ-45 10/100 Base T)
Mains Operating Voltage 100 –120 V @ 60 Hz 220 – 240 V @ 50 Hz
Fuse Rating 5 A (T5AL ~ 250VAC)
Standby Power Consumption <0.5 W (green mode)
Networked Standby Power Consumption <2 W
Weight 5.3 kg (11 lb 10 oz)
Sold As Single Unit
