Fonestar Sky-6 Ceiling Speaker

39

In stock

20W low impedance ceiling speaker, frameless white grille, simple installation only 8cm deep. Resistant against dust and water with an IP-44 rating.

In stock

Description

FEATURES:
– Low impedance ceiling loudspeaker 700;”>
– Low impedance ceiling loudspeaker.
– Low profile frameless grille, constructed from rust resistant aluminium.
  Detachable, turn-lockable. The logo can be removed and the speaker can be painted.
– Fast connection terminals and high conductivity.
– Anti-fall system for installation assistance.
– Hook for safety cable.
– Stable, worm-gear ceiling brackets.
– Protection against dust and water.

POWER:
– 15 W RMS
– 20 W MAX.


SPEAKER:
– 6” polypropylene double cone diaphragm

RESPONSE:
– 55-18,000 Hz @ -10 dB
– 85-7,500 Hz @ -3 dB

IMPEDANCE:
8 Ω

SENSITIVITY:
88 dB @ 1 W/1 m

SOUND PRESSURE:
– 97 dB @ max. W/1m Continuous
– 100 dB @ max. W/1m Peak

COVERAGE ANGLE:
V (-6 dB): 150º@500Hz, 150º@1kHz, 90º@2kHz, 60º@4kHz

PROTECTIONS:

– IP-44 in compliance with EN 60529
– EN ISO 9227:2006 Neutral Salt Spray Test

MATERIAL:
– ABS (UV resistant)
– Liquid paint aluminium grille

CONNECTORS:
– Highly conductive quick-connect terminals
– For 0.4 ~ 4 mm² ross section cable

OPERATION TEMPERATURE:
5ºC ~ 40°C

STORAGE TEMPERATURE:
2ºC ~ 50°C

MAXIMUN HUMIDITY:
0,9

COLOUR:
White (RAL 9003)

DIMENSIONS:
– Total loudspeaker: 249 mm Ø x 85 mm height
– Grille section: 5 mm
– Recessed height: 80 mm
– Installation hole: 219 mm Ø
– Maximum ceiling thickness: 30 mm

WEIGHT:
0.7 kg

ACCESORIES:
Installation template

Additional information

Brand

Fonestar

Speaker Type

Ceiling, In-Wall
